Silver Coated Copper Powder is developed and produced by JBC Co.Ltd.(Korea)

Property

Narrow particle size range

Perfect coating

Good dispersability

Anti-oxidation

Application

Apply to silver pastes (Inks), EMI formulation (pastes), thick film circuit pastes, conductive adhesives, etc.

Package

PE bottle of 2kg/20kg net weight.

Stainless steel drum of 50kg/100kg net weight.

Specification

Item	Particle size distribution (μm )				Tap Density (g/cm3)	Surface Area (m2/g)	Silver (wt%)	Shape
	Ave. Size	D10	D50	D90
S-1703	3	0.5-2.5	2.9-3.5	4.0-5.5	4.5min.	0.4-0.6	17.0±1.0	Spherical
S-1204	4	2.0-3.0	3.7-4.3	4.5-6.0	4.5-5.0	0.3-0.5	12.0±1.0	Spherical
F-1508	8	2.5-4.0	7.0-8.5	15-20	3.0-4.0	0.5-0.7	15.0±1.0	Flake

SEM

•

  S-1703(2000×)

•

  S-1204(2000×)

•

  F-1508(2000×)
